Main technical parameters:

1 bar gauge: 4000mm (1 m / day extension)

2 effective cutting width: 3400mm

3 guide rail length: 6000mm (3 M / h)

4 effective cutting length: 4800mm

5: 1 sets of CNC flame cutting torch single (increase multiple group)

6 CNC plasma: 1-2 (customer optional)

7 automatic ignition: 1 sets (can increase more than group)

8 gas pipe belt device: 1 sets (can be increased more than one group)

9 longitudinal drive: motor, rack

10 line transmission: transverse track, longitudinal rack

11 flame cutting gas: oxygen acetylene (or oxygen propane)

12 machine plasma power supply: user independent selection

13 CNC cutting machine system: Beijing start, Shanghai delivery, USA Haibao

14 drive system / motor: domestic AC servo

15 flame cutting thickness: 6150mm

16 flame perforation cutting thickness: less than 80mm

17 cutting torch lifting distance: 150-220mm

18 machine running speed: 0-3500mm/min

19 set speed error: 0.5mm

20 CNC cutting gun: CNC flame, CNC plasma

Note: the cutting width varies with the number of the torch, guide according to every 3 meters a day lengthened or shortened

1 cutting shape: can be programmed to cut straight lines and arcs of any shape of steel parts;

2 cutting accuracy: national standard JB/T10045.3-99;

3 cutting width: single torch cutting 2400mm;

4 track length: 6000mm standard, also can be customized according to user requirements is extended in section 3000mm/;

5 drive mode: bilateral step / servo drive;

6 torch configuration: Standard 1, optional flame or plasma torch, also can be customized according to user needs;

7 cutting thickness: the maximum flame cutting 200mm, plasma cutting thickness depending on the size of the selected power supply;

8 ignition up: automatic ignition, electric increase, according to user requirements optional capacitive or arc pressure automatic adjustment;

9 NC programming: AutoCAD based fully automatic graphical programming software;
